產品系列

型號: KC46D3
零件號碼: C46D3486NIP--

◎ Auto detection of separate Sync. signal and composite Sync. signal of VGA
◎ Support VGA analog standard input signal (15-pin D-Sub connectors)
◎ Support vertical refresh rate up to 75Hz for VGA~SXGA+ (1400X1050) and
60Hz for higher resolution of VESA standard timing
◎ Supply single pixel(24bits) or dual pixel(48bits) digital RGB output
◎ Compatible with VGA up to Full HD (1920x1080) LCD panel
◎ Operating temperature : 0 °C to +50 °C
◎ Storage temperature : -40 °C to +60 °C
◎ Support Display Port input
◎ Support DVI input
◎ RoHS compliant
◎ DC 12V input
